Antenna type |
External |
Antennas quantity |
4 |
Cabling technology |
10/100/1000Base-T(X) |
Certification |
CE, FCC, RoHS |
Compatible operating systems |
Microsoft Windows 98SE, NT, 2000, XP, Vista™ or Windows 7, 8, 8.1,\n10, MAC OS, NetWare, UNIX or Linux |
DC-in jack |
Y |
Depth |
255 mm |
DHCP client |
Y |
DHCP server |
Y |
Ethernet LAN (RJ-45) ports |
1 |
Ethernet LAN data rates |
10,100,1000 Mbit/s |
Firmware upgradeable |
Y |
Frequency band |
2.4 - 5 GHz |
Height |
72 mm |
Input current |
1.5 A |
Input voltage |
12 V |
LED indicators |
Y |
Maximum data transfer rate |
867 Mbit/s |
Networking standards |
IEEE 802.11a,IEEE 802.11ac,IEEE 802.11b,IEEE 802.11g,IEEE 802.11n |
On/off switch |
Y |
Operating relative humidity (H-H) |
0 - 40 % |
Operating temperature (T-T) |
10 - 90 °C |
Power over Ethernet (PoE) |
Yes |
Receiver sensitivity |
5 GHz: , 11a 6 Mbps: -95 dBm, 11a 54 Mbps: -81 dBm , 11ac VHT20(MCS0): -94 dBm, 11ac VHT20(MCS8): -71 dBm , 11n HT40(MCS0): -91 dBm, 11n HT40(MCS7): -71 dBm , 11ac VHT80(MCS0): -88 dBm, 11ac VHT80(MCS9): -63 dBm , , 2.4 GHz: , 11g 54Mbps: -78 dBm , 11n H |
Reset button |
Y |
Security algorithms |
64-bit WEP,128-bit WEP,WPA,WPA-PSK,WPA2,WPA2-PSK |
Storage relative humidity (H-H) |
5 - 90 % |
Storage temperature (T-T) |
-40 - 70 °C |
WAN connection |
Ethernet (RJ-45) |
Web-based management |
Y |
Width |
400 mm |
Transmitting power (CE) |
|
Transmitting power (FCC) |
|
Service Set Identifier (SSID) features |
Multiple SSIDs |
Maximum data transfer rate (2.4 GHz) |
300 Mbit/s |
Maximum data transfer rate (5 GHz) |
867 Mbit/s |
Fit AP mode features |
Wireless distribution system (WDS) |
Device type identification |
DHCP options |
