Connectivity technology | Wired |
Depth | 7.1 mm |
Frequency range | 2.4 - 5 GHz |
Height | 18.6 mm |
Host interface | USB |
Interface | WLAN |
Internal | No |
Mac operating systems supported | macOS |
Maximum data transfer rate | 433 Mbit/s |
Modulation | 16-QAM, 64-QAM, 256-QAM, CCK, DBPSK, DQPSK, OFDM |
Networking standards | IEEE 802.11a, IEEE 802.11ac, IEEE 802.11b, IEEE 802.11g, IEEE 802.11n, IEEE 802.1x |
Operating relative humidity (H-H) | 10 - 90% |
Operating temperature (T-T) | 0 - 40 °C |
Package height | 30 mm |
Package weight | 90 g |
Package width | 138 mm |
Quick installation guide | Yes |
Security algorithms | 64-bit WEP, 128-bit WEP, WPA-PSK, WPA2-PSK |
Source data-sheet | Icecat.biz |
Storage relative humidity (H-H) | 5 - 90% |
Storage temperature (T-T) | -40 - 70 °C |
USB powered | Yes |
USB version | 2.0 |
Wi-Fi | Yes |
Wi-Fi standards | 802.11a, 802.11b, 802.11g, Wi-Fi 4 (802.11n), Wi-Fi 5 (802.11ac) |
Width | 15 mm |
Windows operating systems supported | Windows 10, Windows 7, Windows 8, Windows 8.1, Windows XP |
WLAN data transfer rates supported | 11,54,150,200,433 Mbit/s |
Transmitting power (CE) | 20 dBm |
Transmitting power (FCC) | 20 dBm |
Antenna direction type | Omni-directional |
Sustainability compliance | Yes |
Harmonized System (HS) code | 85176990 |
Antenna design | Internal |
Compliance certificates | CE, Federal Communications Commission (FCC), RoHS |
