10G support | No |
Basic switching RJ-45 Ethernet ports quantity | 8 |
Basic switching RJ-45 Ethernet ports type | Gigabit Ethernet (10/100/1000) |
Cables included | AC |
Depth | 101 mm |
Ethernet LAN data rates | 1000 Mbit/s |
Flow control support | Yes |
Full duplex | Yes |
Height | 29 mm |
Input current | 1.5 A |
Input voltage | 12 V |
LED indicators | Yes |
MAC address table | 4000 entries |
MIB support | Y |
Networking standards | IEEE 802.3, IEEE 802.3ab, IEEE 802.3u, IEEE 802.3x, IEEE 802.3at, IEEE 802.3af |
Operating altitude | 0 - 3000 m |
Operating relative humidity (H-H) | 0 - 90% |
Operating temperature (T-T) | 0 - 40 °C |
Power over Ethernet (PoE) | No |
Power source | DC |
Quality of Service (QoS) support | Yes |
Source data-sheet | Icecat.biz |
Storage relative humidity (H-H) | 0 - 95% |
Storage temperature (T-T) | -20 - 70 °C |
Switch layer | L2/L3 |
Switch type | Managed |
Switching capacity | 16 Gbit/s |
Web-based management | Yes |
Weight | 500 g |
Width | 158 mm |
