More Info
Details

Technical Headlines

Unmanaged
Quality of Service (QoS) support
Basic switching RJ-45 Ethernet ports quantity: 8
Cat5e 10BASE-T, 100BASE-TX, 1000BASE-T
MAC address table: 4000 entries Switching capacity: 16 Gbit/s
Desktop Rack mounting
DC Power supply included Power over Ethernet (PoE)

PLUG-AND-PLAY
Simple set up with no software to install or configuration needed

NON-BLOCKING SWITCHING
Non-blocking switching architecture for maximum throughput at wire speed

FANLESS DESIGN
Silent operation makes this switch perfect for noise-sensitive environments

VERSITILE MOUNTING OPTIONS
Install your switch on your desktop or mount it to your wall with the hardware provided in the box

ENERGY EFFICIENT
Energy Efficient Ethernet (IEEE 802.3az) standard, which reduces energy consumption when there is light traffic on an active port or when there is no link or no activity detected

FLEX PoE
Easily increase you power budget on this switch to meet your changing power needs.

10G support	No
Auto MDI/MDI-X	Yes
Basic switching RJ-45 Ethernet ports quantity	8
Basic switching RJ-45 Ethernet ports type	Gigabit Ethernet (10/100/1000)
Cable types supported	Cat5e
Copper ethernet cabling technology	10BASE-T, 100BASE-TX, 1000BASE-T
Depth	102 mm
Ethernet LAN data rates	10,100,1000 Mbit/s
Flow control support	Yes
Form factor	Desktop
Full duplex	Yes
Heat dissipation	230.85 BTU/h
Height	27 mm
Housing material	Metal
Input current	1.25 A
Input voltage	54 V
LED indicators	Yes
MAC address table	4000 entries
Mean time between failures (MTBF)	2752476 h
Networking standards	IEEE 802.3az, IEEE 802.1p, IEEE 802.3i, IEEE 802.3u, IEEE 802.3ab, IEEE 802.3x, IEEE 802.3af, IEEE 802.3at
Number of power supply units	1
Operating altitude	0 - 3000 m
Operating relative humidity (H-H)	0 - 90%
Operating temperature (T-T)	0 - 40 °C
Packet buffer memory	0.192 MB
Power over Ethernet (PoE)	Yes
Power over Ethernet (PoE) ports quantity	8
Power source	DC
Quality of Service (QoS) support	Yes
Rack mounting	Yes
Source data-sheet	Icecat.biz
Stackable	No
Storage relative humidity (H-H)	0 - 95%
Storage temperature (T-T)	-20 - 70 °C
Switch type	Unmanaged
Switching capacity	16 Gbit/s
Throughput	16 Gbit/s
Weight	600 g
Width	236 mm
Fanless	Yes
Half duplex	Yes
Power over Ethernet (PoE) type supported	PoE+
MAC address entries	Dynamic MAC address entries
Compliance certificates	CE, Federal Communications Commission (FCC), Industry Canada (IC), RCM, VCCI, KC, CB, Low Voltage Directive (LVD)
