Reasons to Buy
Technical Headlines
Pre-configured for out-of-the-box use
NETGEAR IGMP Plus™ enables instant multicast functionality for most AV over IP installations
Dedicated AV web-based GUI interface
Unique interface designed for the AV professional with color-coded, port-based profiles
Profiles for common audio protocols
Quickly assign profiles to ports for Dante, AES67, and AVB audio configurations. AVB Requires a separate license
Video profiles built-in
Special profiles for NVX, SVSI, Q-SYS and Dante video profiles can be easily assigned to ports as needed
Unique Automatic Configuration
Auto-trunk and auto-lag functionality automatically configures other M4250 switches for use in star topology.
Multi-switch audio or single-switch video deployments
24x1G PoE+ with 300W PoE budget with 2x1G additional ports and 4xSFP 1G fiber uplinks
Layer 2/Layer 3 Switching
Common Layer 2 and Layer 3 switching engine across all M4250 models
Control methods abound
Built-in IT web GUI, console, telnet and SSH consistent with other NETGEAR M4xxx series
Standard network features
Feature set includes static, RIP and PIM routing, DHCP Server and PTPv2
- Pre-configured for out-of-the-box use
- Video profiles built-in
- Dedicated AV web-based GUI interface
- Unique Automatic Configuration
- Profiles for common audio protocols
Technical Headlines
- Managed L2/L3
- Basic switching RJ-45 Ethernet ports quantity: 30
- 1U Rack mounting
- Power supply included Power over Ethernet (PoE)
Pre-configured for out-of-the-box use
NETGEAR IGMP Plus™ enables instant multicast functionality for most AV over IP installations
Dedicated AV web-based GUI interface
Unique interface designed for the AV professional with color-coded, port-based profiles
Profiles for common audio protocols
Quickly assign profiles to ports for Dante, AES67, and AVB audio configurations. AVB Requires a separate license
Video profiles built-in
Special profiles for NVX, SVSI, Q-SYS and Dante video profiles can be easily assigned to ports as needed
Unique Automatic Configuration
Auto-trunk and auto-lag functionality automatically configures other M4250 switches for use in star topology.
Multi-switch audio or single-switch video deployments
24x1G PoE+ with 300W PoE budget with 2x1G additional ports and 4xSFP 1G fiber uplinks
Layer 2/Layer 3 Switching
Common Layer 2 and Layer 3 switching engine across all M4250 models
Control methods abound
Built-in IT web GUI, console, telnet and SSH consistent with other NETGEAR M4xxx series
Standard network features
Feature set includes static, RIP and PIM routing, DHCP Server and PTPv2
| Basic switching RJ-45 Ethernet ports quantity | 30 |
| Basic switching RJ-45 Ethernet ports type | Gigabit Ethernet (10/100/1000) |
| Cables included | AC, LAN (RJ-45), USB Type-C |
| Depth | 257 mm |
| Form factor | 1U |
| Height | 43.2 mm |
| Noise level | 34 dB |
| Power consumption (typical) | 401 W |
| Power over Ethernet (PoE) | Yes |
| Rack mounting | Yes |
| Source data-sheet | Icecat.biz |
| Switch layer | L2/L3 |
| Switch type | Managed |
| User guide | Yes |
| Weight | 4.3 kg |
| Width | 440 mm |
| Fanless | Yes |
| Harmonized System (HS) code | 85176990 |
Specific References
- EAN13
- 0606449151664
NETGEAR GSM4230P-100EUS network switch Managed L2/L3 Gigabit Ethernet (10/100/1000) Power over Ethernet (PoE) 1U Black
NETGEAR GSM4230P-100EUS, Managed, L2/L3, Gigabit Ethernet (10/100/1000), Power over Ethernet (PoE), Rack mounting, 1U
€1,431.66
€1,431.66 Ex. VAT
