Cabling technology | 10/100/1000BaseT(X) |
Certification | FCC, BSMI, VCCI |
Connectivity technology | Wired |
Depth | 120.8 mm |
Ethernet interface type | Gigabit Ethernet |
Ethernet LAN | Yes |
Ethernet LAN (RJ-45) ports | 1 |
Ethernet LAN data rates | 10,100,1000 Mbit/s |
Flow control support | Yes |
Full duplex | Yes |
Height | 21.5 mm |
Host interface | PCI Express |
Interface | Ethernet |
Internal | Yes |
LED indicators | Status |
Maximum data transfer rate | 2000 Mbit/s |
Maximum operating distance | 100 m |
Networking standards | IEEE 802.1Q, IEEE 802.1p, IEEE 802.3, IEEE 802.3ab, IEEE 802.3u, IEEE 802.3x |
Operating relative humidity (H-H) | 10 - 90% |
Operating temperature (T-T) | 0 - 40 °C |
Package height | 30 mm |
Package weight | 100 g |
Package width | 160 mm |
Quality of Service (QoS) support | Yes |
Quick installation guide | Yes |
Source data-sheet | Icecat.biz |
Storage relative humidity (H-H) | 5 - 90% |
Storage temperature (T-T) | -40 - 70 °C |
Width | 78.5 mm |
Windows operating systems supported | Windows 10, Windows 10 Education, Windows 10 Education x64, Windows 10 Enterprise, Windows 10 Enterprise x64, Windows 10 Home, Windows 10 Home x64, Windows 10 IOT Core, Windows 10 IoT Enterprise, Windows 10 Pro, Windows 10 Pro x64, Windows 10 x64, Windows |
Sustainability compliance | Yes |
Harmonized System (HS) code | 85176990 |
Compliance certificates | BSMI, CE, Federal Communications Commission (FCC), RoHS |
