AC adapter included | Yes |
Antenna gain level (max) | 2 dBi |
Cabling technology | 10/100/1000Base-T(X) |
Channels quantity | 2 channels |
DC-in jack | Yes |
Depth | 144.5 mm |
DHCP client | Yes |
DHCP server | Yes |
DMZ support | Yes |
Ethernet LAN | Yes |
Ethernet LAN (RJ-45) ports | 4 |
Ethernet LAN data rates | 10,100,1000 Mbit/s |
Filtering | Yes |
Firewall | Yes |
Firewall security | NAT, SPI |
Firmware upgradeable | Yes |
Height | 80 mm |
LED indicators | LAN, Link, Power, Status, WAN |
Linux operating systems supported | Yes |
Mac operating systems supported | Yes |
Management protocols | HTTP / HTTPS, SSL |
Manual | Yes |
Networking standards | IEEE 802.11a, IEEE 802.11ac, IEEE 802.11b, IEEE 802.11g, IEEE 802.11n, IEEE 802.3, IEEE 802.3ab, IEEE 802.3u |
On/off switch | Yes |
Operating relative humidity (H-H) | 10 - 90% |
Operating temperature (T-T) | 0 - 40 °C |
Output voltage | 12 V |
Quality of Service (QoS) support | Yes |
Reset button | Yes |
Routing protocols | RIP-1, RIP-2 |
Security algorithms | 64-bit WEP, 128-bit WEP, IPSec, WPA, WPA-PSK, WPA2, WPA-PSK2 |
Source data-sheet | Icecat.biz |
Storage relative humidity (H-H) | 5 - 90% |
Storage temperature (T-T) | -40 - 70 °C |
Switching protocols | IPv4, IPv6 |
Universal Plug and Play (UPnP) | Yes |
USB port | Yes |
VPN support | OpenVPN, PPTP VPN, IPSec VPN |
Web-based management | Yes |
Wi-Fi standards | 802.11a, 802.11b, 802.11g, Wi-Fi 4 (802.11n), Wi-Fi 5 (802.11ac) |
Width | 214 mm |
Windows operating systems supported | Windows 10, Windows 2000, Windows 7, Windows 8, Windows 8.1, Windows 98SE, Windows NT, Windows Vista, Windows XP |
Ethernet WAN | Yes |
WLAN data transfer rate (max) | 867 Mbit/s |
ADSL2+ | Yes |
DSL WAN | Yes |
SIM card slot | No |
3G/4G USB modem compatibility | Yes |
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity | 1 |
Stateful Packet Inspection (SPI) | Yes |
ADSL | Yes |
ADSL2 | Yes |
VDSL | Yes |
Antenna direction type | Omni-directional |
Port triggering | Yes |
MU-MIMO technology | Yes |
USB sharing | Yes |
Sustainability compliance | Yes |
Support Samba (storage) | Yes |
Antenna design | Internal |
Wi-Fi Multimedia (WMM)/(WME) | Yes |
Compliance certificates | CE, EAC, RoHS |
Media server | Yes |
