Reasons to Buy

16× Gigabit 802.3at/af-compliant PoE+ RJ45 ports
2× Gigabit RJ45 port, 2× Gigabit SFP port
250W Power Budget, with up to 30W for each PoE port*
Easy to Use: Supports plug-and-play for instant connectivity and simple configuration for additional features
Centralized Cloud Management via the web or the Omada app†
Up to 250m PoE**, QoS△, PoE Auto Recovery‡, and Port Isolation for reliable surveillance networking
Automatic Loop Prevention, VLAN, and IGMP Snooping
Durable metal casing and rack-mountable design

Technical Headlines

Managed L2 Web-based management
Quality of Service (QoS) support
Basic switching RJ-45 Ethernet ports quantity: 18
MAC address table: 8000 entries Switching capacity: 40 Gbit/s
Rack mounting
AC Power supply included Power over Ethernet (PoE)

Omada Cloud Essentials - A Free and Easy Cloud-Based Network Mnagement

Omada Cloud Essentials is a free, easy-to-use cloud-based management option for the Omada networking system, covering access points, switches, and gateways. It enables simple, centralized network management and monitoring with essential features, making it ideal for surveillance networks and small businesses that don't require the complexity of larger operations.

10G support	No
AC input frequency	50/60 Hz
AC input voltage	100 - 240 V
Auto MDI/MDI-X	Yes
Basic switching RJ-45 Ethernet ports quantity	18
Basic switching RJ-45 Ethernet ports type	Gigabit Ethernet (10/100/1000)
Cables included	AC
Depth	180 mm
Firmware upgradeable	Yes
Flash memory	64 MB
Flow control support	Yes
Gigabit Ethernet (copper) ports quantity	18
Heat dissipation	984.88 BTU/h
Height	44 mm
LED indicators	Yes
MAC address table	8000 entries
Mean time between failures (MTBF)	310550.7 h
Networking standards	IEEE 802.1Q, IEEE 802.1ab, IEEE 802.1p, IEEE 802.3ab, IEEE 802.3i, IEEE 802.3u, IEEE 802.3x, IEEE 802.3z
Noise level	41.5 dB
Number of VLANs	32
Operating relative humidity (H-H)	10 - 90%
Operating temperature (T-T)	-5 - 50 °C
Packet buffer memory	4 MB
Power over Ethernet (PoE)	Yes
Power source	AC
Quality of Service (QoS) support	Yes
Rack mounting	Yes
Source data-sheet	Icecat.biz
Stackable	No
Storage relative humidity (H-H)	5 - 90%
Storage temperature (T-T)	-40 - 70 °C
Store-and-forward	Yes
Switch layer	L2
Switch type	Managed
Switching capacity	40 Gbit/s
User guide	Yes
Web-based management	Yes
Width	440 mm
Cloud-managed	Yes
Power over Ethernet (PoE) type supported	PoE+
Compliance certificates	CE, Federal Communications Commission (FCC), RoHS
Unified static configuration	Yes
